Raspberry Pi Pi-hole Nginx Setup: Complete Guide

Imagine blocking unwanted ads and malicious sites on your network. This dream can become a reality with Raspberry Pi, Pi-hole, and Nginx Proxy Manager. This post will guide you through setting up a Raspberry Pi with Pi-hole and configuring Nginx Proxy Manager with Docker.

Before we dive in, here are links to the products used in this article.

– Raspberry Pi 5 16gb: https://t4g.link/raspberrypi
– 128gb MicroSD Card: https://t4g.link/128gbmsd
– Argon ONE V5 Case: https://t4g.link/argonv5
– USB C Card Reader: https://t4g.link/usbccr

🎥 Video Overview

Getting Started: Installing Pi-hole and Docker on Raspberry Pi

Prerequisites:

Before diving into the installation, ensure you have your Raspberry Pi set up with Pi OS and SSH access enabled. Docker should already be installed, and you need to have Portainer for Docker container management.

• Installing Raspberry Pi OS and SSH access:
• Installing Docker and Portainer:

Step 1: Creating Docker Compose File for Pi-hole

Initiate by creating a docker-compose.yml file to structure this whole setup.

sudo nano docker-compose.yaml

sudo nano docker-compose.yaml

Here’s an example of the Docker Compose configuration for Pi-hole.

version: "3"

services:
  pihole:
    container_name: pihole
    image: pihole/pihole:latest
    ports:
      - "53:53/tcp"
      - "53:53/udp"
      - "7300:80/tcp"
      - "443:443/tcp"
      # Uncomment the below if using Pi-hole as your DHCP server
      # - "67:67/udp"
    environment:
      TZ: 'Europe/London' # Time Zones: https://t4g.gg/linux-time-zone-list/
      FTLCONF_webserver_api_password: 'password'
      # Uncomment WEBPASSWORD FOR PIHOLE VERSION 5 AN BELOW
      # WEBPASSWORD: 'password'
    volumes:
      - './etc-pihole/:/etc/pihole/'
      - './etc-dnsmasq.d/:/etc/dnsmasq.d/'
    restart: unless-stopped

version: "3"

services:
  pihole:
    container_name: pihole
    image: pihole/pihole:latest
    ports:
      - "53:53/tcp"
      - "53:53/udp"
      - "7300:80/tcp"
      - "443:443/tcp"
      # Uncomment the below if using Pi-hole as your DHCP server
      # - "67:67/udp"
    environment:
      TZ: 'Europe/London' # Time Zones: https://t4g.gg/linux-time-zone-list/
      FTLCONF_webserver_api_password: 'password'
      # Uncomment WEBPASSWORD FOR PIHOLE VERSION 5 AN BELOW
      # WEBPASSWORD: 'password'
    volumes:
      - './etc-pihole/:/etc/pihole/'
      - './etc-dnsmasq.d/:/etc/dnsmasq.d/'
    restart: unless-stopped

Step 2: Execute the Docker Compose file

sudo docker compose up -d

sudo docker compose up -d

Step 3: Navigating the Pi-hole Dashboard

To access the Pi-hole admin dashboard, open your web browser and enter the Raspberry Pi’s IP address followed by the port 7300. Make sure to enter /admin at the end to reach the dashboard properly.

Installing Nginx Proxy Manager with Docker

Nginx Proxy Manager makes life easier when handling multiple applications requiring SSL and proxying. Create a new directory for this configuration:

sudo mkdir nginx-proxy-manager
cd nginx-proxy-manager
sudo nano docker-compose.yaml

sudo mkdir nginx-proxy-manager
cd nginx-proxy-manager
sudo nano docker-compose.yaml

Nginx Proxy Manager Docker Compose:

version: "3"

services:
  app:
    image: 'jc21/nginx-proxy-manager:latest'
    ports:
      - '80:80' # Public HTTP Port
      - '81:81' # Admin Web Port
      - '443:443' # Public HTTPS Port
    volumes:
      - ./data:/data
      - ./letsencrypt:/etc/letsencrypt
    restart: unless-stopped

version: "3"

services:
  app:
    image: 'jc21/nginx-proxy-manager:latest'
    ports:
      - '80:80' # Public HTTP Port
      - '81:81' # Admin Web Port
      - '443:443' # Public HTTPS Port
    volumes:
      - ./data:/data
      - ./letsencrypt:/etc/letsencrypt
    restart: unless-stopped

Execute the Docker Compose file

sudo docker-compose up -d

sudo docker-compose up -d

Access the Nginx Proxy Manager dashboard by visiting your Raspberry Pi’s IP on port 81. Create your admin account and proceed by logging into the application.

Your Raspberry Pi Is Now An Ad Blocking Machine

Implementing a secure network with Raspberry Pi opens new avenues for home automation and advanced networking. Leveraging Pi-hole for network-wide ad blocking while relying on Nginx for proxy management is just scratching the surface.

Successfully integrating Pi-hole and Nginx Proxy Manager with your Raspberry Pi will not only enhance network security but also provide a flexible infrastructure for various deployments.
